No | Item | Data |
1 | Model | GRL-1200-CB-G |
2 | Structure | Auto Pulp Molding Machine; Shaping and Trimming Molds;Supporting accessories |
3 | Dimension | 6500*5200*4850mm |
4 | Weight | 26T |
5 | Automatic Grade | Automatic forming, drying and automatic trimming |
6 | Safety performance | Fully enclosed , safety control |
7 | Single machine capacity (maximum) | <3500kg/24hr /set (Depending on the product) |
8 | Maximum capacity of 40g lunch box tray | 2500kg/24hr/set |
9 | Max. Product depth | <100 mm Height can be customized |
10 | Whole machine drive power | 30KW |
11 | Horizontal movement | servo motor |
12 | Hot pressing method | Hydraulic drive |
13 | Hot pressing pressure | Max. 50Ton |
14 | Edge trimming machine pressure | Max. 60Ton |
15 | Heating Method | Accept electric heating or heat conduction oil heating |
16 | If electric heating is installed | The installed heating power is 250kw, and the maximum can be designed to 400kw |
17 | Control system | Siemens PLC+ Siemens touch screen |
